Descripción
Typical Tensile Properties
| M21 shielding gas EN As welded | ||
| Elongation | Tensile Strength | Yield Strength |
| 28 % | 569 MPa | 456 MPa |
Propiedades de Ensayo de impacto Charpy
| M21 shielding gas EN As welded | |
| Impact Value | Testing Temperature |
| 145 J | -20 °C |
| 129 J | -30 °C |
| Aprobaciones: | CE, EN 13479, DB, 42.039.12, DB, 81.039.03, DNV, III YMS (M21), GL, 3Y H10S, LR, 3YS H5 (M21), RINA, 3YS H5 (M21), VdTÜV, 02181 |
| Clasificaciones: | SFA/AWS A5.36, E71T5-M21A2-CS1-H4, SFA/AWS A5.36, E71T5-C1A2-CS1-H4, Weld Metal, EN ISO 17632-A, T 42 3 B C 2 H5, Weld Metal, EN ISO 17632-A, T 42 3 B M 2 H5, Weld Metal |
Aprobaciones vinculadas a la planta de producción. Para obtener más información, pongase en contacto con ESAB.
| Alloy Type: | C Mn |
| Diffusible Hydrogen: | < 4 ml/100g |
| Welding Current: | DC- |
